Description
Anycubic Standard Resin V2 in HD Grey is a reformulated photopolymer resin for 405nm LCD and DLP resin 3D printers, offering enhanced toughness, impact resistance and dimensional accuracy. Its low-viscosity formula promotes fast resin flow and bubble dissipation while retaining fine surface detail, while the low-odour formulation provides a more comfortable printing environment.
With a 4.3–5.6% volumetric shrinkage rate, the resin is designed to minimise deformation and maintain accurate reproduction of the original model. Its balanced strength and flexibility make it suitable for figurines, action figures, electronic housings, tooling fixtures, snap-fit components, prototypes and other detailed functional parts. Pre-configured profiles are available in Anycubic Photon Workshop for consistent printing results.
Key Features
- Enhanced toughness and impact resistance
- Flexible characteristics help reduce brittle fracture
- 4.3–5.6% volumetric shrinkage for improved dimensional accuracy
- Low-viscosity formula for fast resin flow and bubble dissipation
- Fine-detail reproduction with clean surface finish
- Low-odour formulation
- Compatible with 405nm UV-curing LCD and DLP 3D printers
- Pre-configured profiles available in Anycubic Photon Workshop
- Clean prints with ≥95% IPA
- 405nm UV post-curing support
Specifications
- Colour: HD Grey
- Resin size: 1kg
- Material: Photopolymer Resin
- Wavelength: 365–405nm
- UV wavelength: 405nm
- Viscosity: 250–350 mPa·s at 25°C
- Density: 1.05–1.25 g/cm³
- Hardness: 80–83 HD
- Tensile strength: 35–45 MPa
- Elongation at break: 25–30%
- Bending modulus: 40–50 MPa
- Bending strength: 1500–2100 MPa
- Young’s modulus: 1200–1400 MPa
- Izod impact strength: 192 J/m
- Volume shrinkage rate: 4.3–5.6%
- Recommended print environment: 20–40°C
- Print temperature: 20–50°C
- First layer exposure: 20–40 seconds
- Normal exposure: 2.5–3 seconds
- Cleaning: ≥95% IPA
- Recommended washing duration: ≥3 minutes
- Curing temperature: 18–30°C
- UV intensity: 25,000–30,000 µW/cm²
- Recommended curing time: 3 minutes
- Disposal: Post-UV-cured resin may be treated as plastic waste
What’s in the Box
- Anycubic Standard Resin V2 – HD Grey 1kg × 1
